Adding measurements to steps

Feature Requests
1

Being able to add measurements to steps can be helpfull. This doesn’t have to be measured in Cadasio.

But being able to click one edge and an other, and then manually add the distance can be good enough.

1 Like
2

Hi @user5789 ,

thanks for logging this. It has been raised before, so I will add you to the existing enhancement request, as the more people ask for something the sooner we will get it in. Just so I can put a bit of weight behind this, how important would this be for you? Perhaps on a scale of 0 [not important, just nice to have] - 10 [business critical]

3

For our buisness this would be an easy 9 or even 10.

Some of our instructions just need one or two measurements to be understandable.

Thx for the quick response!

1 Like
4

Hi. It would be usable for us too.

5

This is certainly a feature that would take this tool from really useful to pretty much perfect for our business. Would save our designers (and me) so much time & we could move our instructions solely to Cadasio!

1 Like
6

Same here, We don’t need many measurements but it would sure be nice to add them neatly.

7

I would give this a 5-6 in our case. Not mission critical but would definitely add value.

8

Would be handy feature for us as well. Any update on the process?

9

Hi @PerLondin ,

Internally, a member of the team has actually started scoping this out to see what’s possible, and how to achieve certain dimension types.

There is still some way to go, adding the dimensions in 3D is challenging and then of course we have to ensure the interface is built, and that it works as people intend, so at this stage we can’t give an ETA.

It would be useful to know the types of dimensions you wish to see, and how you would want it to behave.

10

This feature would also be really helpful for our company as well, if I were to guess around an 8 or a 9. I think it would even be fine just to show the user the dimensions created by the underlying cad program, but I’m not sure if that is easier or harder for you guys to implement. At some point it would be really cool to have dimensions where when the user hovers their mouse over them the line or angle etc. that is being dimensioned it becomes highlighted. Thanks for listening to everyone’s feedback!
